Applied to heavy machinery, hydraulic equipment, electric vehicle control

•Positioning method: spring automatic return/resistance positioning

•Mechanical gear: feel of mechanical gear (limited resistance positioning)

• Sensor: Hall sensor

• Direction switch: 2pcs 2A/12V Operating angle: ±34°, total angle 68°

• Power supply: DC5V/12-29V

• Signal output: voltage 0-5V, USB, CAN

PWM (0-500mA) proportional valve signal

•Life: 5 million times; accuracy: less than 0.8%.

•Material: aluminum alloy, stainless steel

•Protection grade: IP65 above the panel

• Proportional valve control with acceleration and deceleration, Curve, maximum current, minimum current setting function
